PM Series 850M
Efficient, Quiet Power
Certified 80+ Gold, this PSU delivers clean and efficient energy while reducing heat. The 13.5cm HDB fan stays quiet even during intense loads.
Built for Next-Gen Hardware
Fully compliant with ATX 3.1 and PCIe 5.1, this PSU is future-ready. The native 12VHPWR (600W) PCIe 5.1 connector supports the latest high-power GPUs right out of the box—no adapters, no bottlenecks. Just clean, direct power and safer, more reliable connections.
Modular for a Cleaner Build
Fully modular cabling gives you control over cable routing and aesthetics. Remove clutter, maximize airflow, and simplify upgrades.
Full Japanese Capacitor Build
Built with 100% Japanese capacitors rated for 100,000 hours, this PSU ensures consistent voltage and thermal stability. It's engineered for long-term reliability under high-performance conditions.
Full Protective Circuit Suite
Equipped with 8 comprehensive safety mechanisms: OVP, SCP, OPP, UVP, OTP, OCP, SIP, and NLO—this PSU actively shields your components from power surges, shorts, and instability. It's peace of mind in every watt.
| Modular Type | Fully Modular |
|---|---|
| Continuous Power | 850W |
| ATX Standard | ATX 3.1 |
| Efficiency Level | 80 plus Gold |
| PFC | Active PFC |
| Capacitor | All Japanese Capacitors |
| MTBF | 100,000 hrs @ 25°C |
| Input Voltage | Full Range (100V-240V) |
| Protection | OVP, SCP, OPP, UVP, OTP,OCP, SIP, NLO |
| DC to DC | Yes |
| AMB | Capable of full wattage output at an ambient temperature of 40℃ |
| Fan size/Fan Speed | 13.5cm /1500RPM |
| Fan Bearing Type | Hydro Dynamic Bearing (HDB) |
| Combined Power | 100W |
| Current | 20A |
| Cable List | ATX 24 PIN x1 (23.6‘’) EPS 4 + 4PIN x1 (25.5‘’ + 5.9”) PCI-E 6 + 2 x2 (19.6” + 5.9”) PCI-E 5.1 (600W) x1 (23.6‘’) SATA x3 (19.6‘’+5.9‘’+5.9‘’+5.9‘’) MOLEX x1 (19.6‘’+5.9‘’+5.9‘’+5.9‘’) Floppy (5.9") |
| Color | Dark Gray |
| Material | Metal |
| Dimensions | 150*150*86mm/5.9*5.9*3.39in |
| Net. Weight | 2.33kg/5.14lb |
| Warranty | 10 Years US|MX|ES |
YFG-8503M-P1_Power-Supply_Brochure-desk_ENG.pdf
